Anchor point WADIR

Robust lifeline — fall arrest systems

See product details

Available in 1 version

Show variant
Exclusively for trade customers

Register now and access more than 125,000 products

Variants

Exclusively for trade customers

Register now and access more than 125,000 products

Login/Registration
Find your nearest point of sale
Customer Service: 0471 828 000

Component can be used on concrete and steel



Numerous options for securing to the supporting structure (with compound anchor and threaded rod, bolts)



In the event of a fall, the anchoring device may deform without breaking, and can resist a nominal arrest load of 900 daN



The anchoring device may be used for rescue operations only within its operational limits and if in perfect working order



Advantages of A2 (AISI 304) stainless steel:


  • remains unchanged over time, being resistant to weather induced corrosion

  • because of its intrinsic characteristics, the material can dissipate more energy, in the event of a fall, compared to zinc-plated steel, thereby reducing the need for maintenance operations on the attachments and on the connection structure
Notice

Suitable for 1 operator equipped with appropriate personal protective equipment (PPE), which in the event of a fall, must not generate a load of more than 6 kN


Also suitable for use in restraining operations


Not suitable for creating anchor lines



The deflection and displacement values refer to the load condition relative to the fall arrest of the first user



Warranty:


10 years for materials (from the date of purchase)



Anchorage to the load-bearing structure:


The support must be assessed and the anchor must be sized by a qualified technician. The suitability of the support for absorbing the stress exerted by the falling operator must always be tested (see standard UNI 11560:2022)



Certifications:


The anchoring device has undergone the tests required by standard UNI 11578:2015 and is compliant with type A. The ideal number of operators for using this device is stated in the catalogue. The certification will no longer be valid if the product is disassembled, altered, modified or improperly installed. Certifications can be downloaded from the website: www.wuerth.it/progettisti/prodotti/linea-vita/



Periodic inspection:


The anchoring system is subject to regular mandatory inspection at intervals of no more than 2 years, as required by Point 9.2.3. of standard UNI 11560:2022. The regular inspections must be performed by the intermediate installer and/or qualified technician, always assuming liability for the activity undertaken. The checks to be performed refer to the table 1, 2 and 3 of UNI 11560:2022



Further information:


Please refer to the information pages, the installation and operation manual and the system handbook supplied with the products. These documents can be downloaded from the website: www.wuerth.it/progettisti/prodotti/linea-vita/
